• High Torque 12V Micro DC Planetary Gear Motor For Braking System , High Precision
    • High Torque 12V Micro DC Planetary Gear Motor For Braking System , High Precision
  • High Torque 12V Micro DC Planetary Gear Motor For Braking System , High Precision

    High Torque 12V Micro DC Planetary Gear Motor For Braking System , High Precision

    Product Details:

    Place of Origin: China
    Brand Name: ZHAOWEI
    Certification: CE/ROHS/ISO9001/ISO14001/SGS/TS16949
    Model Number: ZWBPD032032-763

    Payment & Shipping Terms:

    Minimum Order Quantity: 500pcs
    Price: negotiation
    Packaging Details: packed in nylon firstly, then carton, and then reinforced with wooden case for outer packing
    Delivery Time: 15 working days after payment
    Payment Terms: T/T, Western Union
    Supply Ability: 600,000pcs per month
    Get Best Price Contact Now

    Detail Information

    Type: Plastic Planetary Gearbox Voltage: 12V DC
    Load Speed: 6 Rpm Load Current: 715mA
    No Load Speed: 7 Rpm No Load Current: 265mA
    Load Torque: 25,000 Gf.cm Gear Ratio: 763:1
    High Light:

    speed reducer gearbox

    ,

    brushed dc electric motor

    Product Description

    High Torque 12V Micro DC Planetary Gear Motor For Braking System , High Precision

    POM Gears 763:1 Reduction Ratio High Torque 12V DC Planetary Geared Motor

    Specifications:


    Can be customized

    24V plastic DC gear motor


    Model
    Application Parameters Rated Torque of Gear Box Instant Torque of Gear Box Gear Ratio Gear Box Length
    Rated At No Load At Rated Load Overall Length
    Voltage Speed Current Speed Current Torque
    VDC rpm mA rpm mA gf.cm mN.m mm gf.cm gf.cm mm
    ZWBPD032032-16 12.0 337 215 303 715 1229 121 78.2 25000 80000 16 35.7
    ZWBPD032032-24 12.0 225 215 202 715 1843 181 25000 80000 24
    ZWBPD032032-33 12.0 163 215 147 715 2534 249 20000 80000 33
    ZWBPD032032-67 12.0 80 230 72 715 3392 333 88.2 25000 80000 67 45.7
    ZWBPD032032-94 12.0 57 230 52 715 4759 467 25000 80000 94
    ZWBPD032032-133 12.0 41 230 36 715 6733 660 25000 80000 133
    ZWBPD032032-188 12.0 29 230 26 715 9518 933 20000 80000 188
    ZWBPD032032-272 12.0 20 265 18 715 10328 1013 98.2 25000 80000 272 55.7
    ZWBPD032032-383 12.0 14 265 13 715 14542 1426 25000 80000 383
    ZWBPD032032-540 12.0 10 265 9 715 20503 2011 25000 80000 540
    ZWBPD032032-763 12.0 7 265 6 715 25000 2452 25000 80000 763
    ZWBPD032032-1076 12.0 5 265 5 715 20000 1961 20000 80000 1076

    above specifications just for reference and customizable according to requirements.



    ZWBPD032032PDF.pdf

    2D Drawing
    High Torque 12V Micro DC Planetary Gear Motor For Braking System , High Precision 0

    Product details show:
    12V DC Geared Motor

    Application:



    Smart wearable devices watch,VR,AR,XR and etc.
    Household application kitchen appliances, sewing machines, corn popper, vacuum cleaner, garden tool, sanitary ware, window curtain, intelligent closestool, sweeping robot, power seat, standing desk, electric sofa, TV, computer, treadmill, spyhole, cooker hood, electric drawer, electric mosquito net, intelligent cupboard, intelligent wardrobe, automatic soap dispenser, UV baby bottle sterilizer, lifting hot pot cookware, dishwasher, washing machine, food breaking machine, dryer, air conditioning, dustbin, coffee machine, whisk,smart lock,bread maker,Window cleaning robot and etc.
    communication equipment 5G base station,video conference,mobile phone and etc.
    Office automation equipments scanners, printers, multifunction machines copy machines, fax (FAX paper cutter), computer peripheral, bank machine, screen, lifting socket, display,notebook PC and etc.
    Automotive products conditioning damper actuator, car DVD,door lock actuator, retractable rearview mirror, meters, optic axis control device, head light beam level adjuster, car water pump, car antenna, lumbar support, EPB, car tail gate electric putter, HUD, head-up display, vehicle sunroof, EPS, AGS, car window, head restraint, E-booster, car seat, vehicle charging station and etc.
    Toys and models radio control model, automatic cruise control, ride-on toy, educational robot, programming robot, medical robot, automatic feeder, intelligent building blocks, escort robot and etc.
    Medical equipments blood pressure meter, breath machine, medical cleaning pump, medical bed, blood pressure monitors, medical ventilator, surgical staplers, infusion pump, dental instrument, self-clotting cutter, wound cleaning pump for orthopedic surgery,electronic cigarette, eyebrow pencil,fascia gun, , surgical robot,laboratory automation and etc.
    Industrials flow control valves, seismic testing,automatic reclosing,Agricultural unmanned aerial vehicle,automatic feeder ,intelligent express cabinet and etc.
    Electric power tools electric drill, screwdriver,garden tool and etc.
    Precision instruments optics instruments,automatic vending machine, wire-stripping machine and etc.
    Personal care tooth brush, hair clipper, electric shaver, massager, vibrator, hair dryer, rubdown machine, scissor hair machine, foot grinder,anti-myopia pen, facial beauty equipment, hair curler,Electric threading knife,POWER PERFECT PORE, Puff machine,eyebrow tweezers and etc.
    Consumer electronics camera, mobile phone,digital camera, automatic retracting device,camcorder, kinescope DVD,headphone stereo, cassette tape recorder, bluetooth earbud charging case, turntable, tablet,UAV(unmanned aerial vehicle),surveillance camera,PTZ camera, rotating smart speaker and etc.
    robots educational robot, programming robot, medical robot, escort robot and etc.



    Our Services
    • ODM & OEM
    • Gearbox design and development
    • Related technology support
    Packaging & Shipping



    1) Packing Details



    packed in nylon firstly, then carton, and then reinforced with wooden case for outer packing.

    Or according to client's requirement.



    2) Shipping Details



    samples will be shipped within 10 days;

    batch order leading time according to the actual situation.



    Company Information

    Shenzhen ZHAOWEI Machinery & Electronics Co., Ltd was established in 2001,We provide the total drive solution for customers from design, tooling fabrication, components manufacturing and assembly.


    1) Competitive Advantages

    • Years of experience in producing miniature motor gearboxes
    • We provide technical support from r&d, prototype, testing, assembly and serial production , ODM &OEM
    • Competitive Price
    • Product Performance: Low noise, High efficiency, Long lifespan
    • Prompt Delivery: 15 working days after payment
    • Small Orders Accepted

    2) Main Products



    • Precision reduction gearbox and its diameter:3.4mm-38mm,voltage:1.5-24V,power: 0.01-40W,output speed:5-2000rpm and output torque:1.0 gf.cm -50kgf.cm,

    • Customized worm and gear transmission machinery;
    • Precise electromechanical motion module;
    • Precise component and assembly of plastic and metal powder injection.



    Production&Equipment

    .jpg

    FAQ



    1. Can you make the gearbox with custom specifications?

    YES. We have design and development team, also a great term of engineers, each of them have many work years experience.



    2.Do you provide the samples?

    YES. Our company can provide the samples to you, and the delivery time is about 5-15days according to the specification of gearbox you need.



    3.What is your MOQ?

    Our MOQ is 2000pcs. But at the beginning of our business, we accept small order.



    4. Do you have the item in stock?

    I am sorry we donot have the item in stock, All products are made with orders.



    5. Do you provide technology support?

    YES. Our company have design and development team, we can provide technology support if you need.



    6.How to ship to us?

    We will ship the goods to you according to the DHL or UPS or FEDEX etc account you provide.



    7.How to pay the money?

    We accept T/T in advance. Also we have different bank account for receiving money, like US dollors or RMB etc.



    8. How can I know the product is suitable for me?

    Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.



    9. Can I come to your company to visit?

    YES, you can come to our company to visit at anytime, and welcome to visit our company.



    10. How do contact us ?

    Please send an inquiry
